Creative Sound BlasterX G6 Audio Portable Sound Card /7.1 HD Gaming DAC and External USB

Amplifier

for PS4, Xbox One, Nintendo Switch, and PC

Specifications

Weight

144 g

Interface/Power

USB 2.0, USB Bus Powered

DAC

Dynamic Range: 130dB (A-weighted), THD+N: ~0.0002%, Sampling Rate (DSP Playback): PCM 16/24/32-bit / 44.1, 48.0, 88.2, 96.0kHz, Sampling Rate (Direct Mode Playback): PCM 16/24/32-bit / 44.1, 48.0, 88.2, 96.0, 176.4, 192.0, 352.8, 384.0 kHz, DoP 24-bit / 176.4 , 352.4 kHz

ADC

Dynamic Range: 114dB (A-weighted), THD+N: 0.0006%, Sampling Rate (Mic-in): 16/24/32-bit / 44.1, 48.0, 88.2, 96.0, 176.4, 192.0 kHz, Sampling Rate (Line-in, Optical-In): 16/24/32-bit / 44.1, 48.0, 88.2, 96.0, 176.4, 192.0 kHz, Output Impedance: 1 Ω, Supported Headphone Impedance: 16 - 600 Ω, High Gain: 150 - 600 Ω (+14dB), Low Gain: 16 - 149 Ω (+0dB)

Audio Technology

SB-Axx1™

Connectivity Options (Main)

1 x ⅛″ Line In/mini TOSLINK In Combo Jack, 1 x ⅛″ Line Out/mini TOSLINK Out Combo Jack, 1 x ⅛″ Headphone/Headset Jack, 1 x ⅛″ Ext. Mic In Jack, 1 x microUSB port for PC/Mac

Audio Technologies

Scout Mode

Supported Operating Systems

Windows® 7, Windows® 8, Windows Vista®, Windows® 8.1, Windows® 10, Mac OS X v10.8 and above

Included Accessories

microUSB cable, Mini TOSLINK Cable

Dimensions

111 x 70 x 24 mm

ASIO

Playback & Recording

Recommended Usage

Gaming

System Requirements

Windows® OS

Intel® Core™i3 or AMD® equivalent processor

Intel, AMD or 100% compatible motherboard

Microsoft® Windows 10 32/64 bit, Windows 8.1/8.0 32/64 bit, Windows 7 32/64 bit

1GB RAM

>600 MB of free hard disk space

USB 2.0 / USB 3.0 port

Mac® OS

Mac OS X® 10.9 or higher

1GB RAM

USB 2.0 / USB 3.0 port

PS4

Firmware Version 5.0 or later

Available USB port

Available Optical Out port (for Dolby Digital decoding)

Xbox One

Xbox OS Version 10.0 or later

Available Optical Out port (for Dolby Digital decoding)

External USB Power (not included)

Voice communications not supported

Nintendo Switch

Switch OS 5.0 or later

Available 3.5mm headphone port

Available USB port (in docking mode)

External USB Power (not included)

Voice communications not supported

Package Contents

Sound BlasterX G6

1 x Optical Cable

1 x MicroUSB Cable

Quick Start Leaflet

Warranty Leaflets

View Windows® 10

Software Availability Chart

Warranty

1-year Limited Hardware Warranty
